Fire Rated Rolling Shutters

A spark can set a whole forest on fire, so to avoid that fire protection system need to be executed by every individual!

Importance of fire rated rolling shutters

If you are running a business, then you should be very careful regarding fire incidents. At that time fire protection systems are a fundamental necessity in running a business as fire can easily sweep away everything you have worked so hard for. It is one of the greatest enemies of various organizations, especially organizations including shopping centers, hospitals, school canteens, restaurants etc.

A proficient framework for fire prevention must be created to secure the business property against fire. Different sorts of equipment should work hand in hand to limit the damage that fires can cause. Our Fire rated rolling shutters are among the modern equipment that is used to compartmentalize a building in order to help prevent the fire from spreading. Only here you get the best fire rated rolling shutters!

Our organization is delicately engaged in the business of supplying Fire rated rolling shutters. It is manufactured using high grade galvanized steel, our whole range is planned in consistence with worldwide quality measures. Further, our entire range of fire rated rolling shutter doors can be supplied depending on your requirements, and they are tested to BS476 part 22: 1977.

Features Fire Rated Rolling Shutters -

  • Smooth sliding door
  • Anti-corrosive
  • Adequate safety features
  • Strong and reliable
  • Offers 21DB sound reduction value
  • Provides radiant heat protection

These fire rated rolling shutters are fitted with safety brakes, coupled with drive ratio control that consists of Interface panels so that the Fire rated roller shutter closes automatically when the fire alarm is set off.

So, for highly efficient Fire rated rolling shutters contact us at:

Applications and Use

Names Fire Rated Shutter Code FR75 , FR100
Materials Galvanize Double Wall Silicon Insulated Strip Standard Colour Silver or Customized
Single-Plate Height 75 mm , 100 mm Thickness 25 mm
Size According to your request Open Style Ovehead Upwards
Frames Steel Open Way Electronic /Manual
Application commercial, high-grade shops, super malls, exhibition centre, etc.

Specification/Technical Details:

Max width 9000 mm
Max height 9000 mm
Speed (frequency control system)
Max open speed 0.200m/s~0.300m/s , adjustable
Max close speed 0.200m/s~0.300m/s, adjustable
Door panel
Material Galvanize Double Wall Silicon Insulated Strip
Thickness 25mm
Color Silvery or Customized
Rated Upto 2 to 4 hrs
Drive System
Motor Germany SEW/Equivalent Motor
Power output 380V or 220V/50HZ 0.75KW/ 1.1KW/1.5KW
Control System
PLC German/Italian technology
Inverter German Approved brand
Encoder German Approved brand
Opening Way
Customized Way Double-side radar / Infrared sensors and so on
