Fire Rated Rolling Shutters
A spark can set a whole forest on fire, so to avoid that fire protection system need to be executed by every individual!
Importance of fire rated rolling shutters
If you are running a business, then you should be very careful regarding fire incidents. At that time fire protection systems are a fundamental necessity in running a business as fire can easily sweep away everything you have worked so hard for. It is one of the greatest enemies of various organizations, especially organizations including shopping centers, hospitals, school canteens, restaurants etc.
A proficient framework for fire prevention must be created to secure the business property against fire. Different sorts of equipment should work hand in hand to limit the damage that fires can cause. Our Fire rated rolling shutters are among the modern equipment that is used to compartmentalize a building in order to help prevent the fire from spreading. Only here you get the best fire rated rolling shutters!
Our organization is delicately engaged in the business of supplying Fire rated rolling shutters. It is manufactured using high grade galvanized steel, our whole range is planned in consistence with worldwide quality measures. Further, our entire range of fire rated rolling shutter doors can be supplied depending on your requirements, and they are tested to BS476 part 22: 1977.
Features Fire Rated Rolling Shutters -
- Smooth sliding door
- Anti-corrosive
- Adequate safety features
- Strong and reliable
- Offers 21DB sound reduction value
- Provides radiant heat protection
These fire rated rolling shutters are fitted with safety brakes, coupled with drive ratio control that consists of Interface panels so that the Fire rated roller shutter closes automatically when the fire alarm is set off.
So, for highly efficient Fire rated rolling shutters contact us at: www.standardautomation.in.
Applications and Use
| Names | Fire Rated Shutter | Code | FR75 , FR100 |
|---|---|---|---|
| Materials | Galvanize Double Wall Silicon Insulated Strip | Standard Colour | Silver or Customized |
| Single-Plate Height | 75 mm , 100 mm | Thickness | 25 mm |
| Size | According to your request | Open Style | Ovehead Upwards |
| Frames | Steel | Open Way | Electronic /Manual |
| Application | commercial, high-grade shops, super malls, exhibition centre, etc. |
Specification/Technical Details:
| Size | |
|---|---|
| Max width | 9000 mm |
| Max height | 9000 mm |
| Speed (frequency control system) | |
| Max open speed | 0.200m/s~0.300m/s , adjustable |
| Max close speed | 0.200m/s~0.300m/s, adjustable |
| Door panel | |
| Material | Galvanize Double Wall Silicon Insulated Strip |
| Thickness | 25mm |
| Color | Silvery or Customized |
| FireProof | |
| Rated | Upto 2 to 4 hrs |
| Drive System | |
| Motor | Germany SEW/Equivalent Motor |
| Power output | 380V or 220V/50HZ 0.75KW/ 1.1KW/1.5KW |
| Control System | |
| PLC | German/Italian technology |
| Inverter | German Approved brand |
| Encoder | German Approved brand |
| Opening Way | |
| Customized Way | Double-side radar / Infrared sensors and so on |
